Bag in box

Meet the bag in box

SEMI-AUTOMATIC BAG IN BOX FILLER

  • It concentrates the highest degree of sterility during filling.
  • The compact design and the elimination of a large number of mechanical parts simplify maintenance and ensure the safety of the entire filling process.
  • It can have up to 1 filler neck.
  • Optional laminar air flow format for ultra-clean filling conditions.
SEMI-AUTOMATIC BAG IN BOX FILLER
New

Features of the semi-automatic bag in box filler

BAG IN BOX

The bag in box fillers are suitable for:
  • Foamy, viscous, corrosive, abrasive, flammable, flowable products with solid particles in suspension.

Examples: Mineral oils, paints, isocyanates and solvents, glues and adhesives, waxes, fertilizers, herbicides, seed cures, automotive products, detergents, bleaches.

Format
  • Filling of Bag in Box or Pouch Up type bladders, with Vitop, Press-Top and Flex-Top type lids.
Technical features:
  • Robust AISI 304 or AISI 316 stainless steel structure.
  • Parts in contact with the products according to their needs (stainless steel AISI 316, PVC, Titanium, EPDM, Viton, Teflon gaskets).
  • Operator panel for PLC programming and control of the equipment.
  • Electrical and pneumatic elements of leading brands.
Variables:
  • L-Mag, volumetric flow meter.
  • L-Mass, mass flow meter.
Benefits:
  • Temperature range of the product to be filled from -10° C to 125° C.
  • Perfect adaptation to all types of liquids.
  • Maximum precision and repeatability of dispensed volumes.
  • Adjustment and variation of volumes with touch screen and possibility of countless recipes.
  • Great versatility in format changes.
  • Fast, tool-less format changes.
  • Quick adjustment of the different container dimensions and volumes to be dispensed.
  • Programmable cleaning speed depending on the products (cleaning quality improved and cleaning times reduced)
  • Low quantity of washing liquid.
  • Cleaning in place (CIP) and sterilization in place (SIP) as standard (150° C for 60 minutes)
  • Simple and linear filling circuit, without mechanical moving parts
